Pebax and Stainless-steel braiding
provides outstanding pushability and crossability.
Double braiding with 32 strands
Designed to achieve 1:1 torque and for excellent support
Soft tip
reduces potential for vessel trauma.
Large inner lumen and ultra-thin wall,
ensures high flow rate of contrast media.
Reinforced shaft can resist up to 1200psi pressure and maintain flexibility
Inner Lumen Sizes
4F 0.042”(1.00mm)
5F 0.046”(1.17mm)
6F 0.054”(1.37mm)
7F 0.064”(1.62mm)
Color hub for easy indentification
Maximum guidewire size:0.038”/0.97mm
Maximum pressure:1200psi/84bar
