FEATURES

1).Smooth plunger action;

2).Transparent Cylinder & Precise Graduations;

3).Plunger design holds negative pressure with ease and won‘t inadvertently disengage;

4).Dual use: can be used as a vacuum syringe or as a standard syringe.

Ordering Information:

INDICATIONS FOR USE

The Syringe is intended to be used by a cardiologist or radiologist during angiographic or radiologic procedures.

CLINICAL BENEFITS

Administration or withdrawal of fluids or the creation of a vacuum during appropriate procedures.

INSTRUCTIONS FOR USE

1. To setup the syringe to lock, move the plunger completely forward or completely back and turn the plunger so that the locking fins can engage the stop pin.

2. To create and maintain vacuum, withdraw the syringe plunger to the desired position and rotate the plunger clockwise to position one of the locking fins behind the stop pin.

3. Turn the plunger counterclockwise to release.

4. To aspirate fluids without locking the syringe, move the plunger completely forward or completely back, turn the plunger so that the locking fins will not interfere with the stop pin.
